| Model Name | SKU | Card Technology | Data Output | Housing/Form Factor | Connector |
|---|---|---|---|---|---|
| Wave ID® Plus Keystroke OEM Module USB Reader | OEM-805N1AKU | HID™ Prox, AWID, CASI-RUSCO, EM 410x (4100/4102/4105/4200), Honeywell Nexwatch, Indala, Kantech ioProx, HID™ iCLASS™ CSN, ISO 14443A CSN, ISO 15693 CSN, MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, LEGIC Advant CSN (ISO 15693 / 14443A), aptiQ™ MIFARE® CSN, Bosch ReadyKey Pro UID, Cardax UID, CDVI, Corbin Russwin® UID, DIGITAG, Farpointe Data Pyramid, GProx-II UID, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, ID Teck UID, Infineon my-d™ CSN, I-tag CSN, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, NFC Type 2 CSN, NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey e*tag® CSN, SecuraKey-02 Radio Key®, Texas Instruments Tag-It CSN, XceedID® MIFARE® CSN, Philips/NXP | Keystroke | Non-Housed | USB-A |
| WAVE ID® Plus SDK OEM Module USB Reader | OEM-805N2AKU | HID™ Prox, AWID, CASI-RUSCO, EM 410x (4100/4102/4105/4200), Honeywell Nexwatch, Indala, Kantech ioProx, HID™ iCLASS™ CSN, ISO 14443A CSN, ISO 15693 CSN, MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, LEGIC Advant CSN (ISO 15693 / 14443A), aptiQ™ MIFARE® CSN, Bosch ReadyKey Pro UID, Cardax UID, CDVI, Corbin Russwin® UID, DIGITAG, Farpointe Data Pyramid, GProx-II UID, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, ID Teck UID, Infineon my-d™ CSN, I-tag CSN, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, NFC Type 2 CSN, NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey e*tag® CSN, SecuraKey-02 Radio Key®, Texas Instruments Tag-It CSN, XceedID® MIFARE® CSN, Philips/NXP | Raw Data | Non-Housed | USB-A |
| WAVE ID® Plus V2 w/ iCLASS ID & SEOS Black Virtual COM Reader | RDR-80081AK0 | HID™ Prox, AWID, CASI-RUSCO, EM 410x (4100/4102/4105/4200), NFC Type 3 CSN (Felica), Honeywell Nexwatch, Indala, Kantech ioProx, HID™ iCLASS™ CSN, HID™ iCLASS, HID™ iCLASS SE™, HID™ iCLASS Seos™, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, LEGIC Advant CSN (ISO 15693 / 14443A), aptiQ™ MIFARE® CSN, Bosch ReadyKey Pro UID, Cardax UID, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, ID Teck (128 Bits), Infineon my-d™ CSN, ISONAS™, I-tag CSN, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey e*tag® CSN, SecuraKey-02 Radio Key®, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | USB Virtual Com | |
| Wave ID® Plus V2 w/ iCLASS ID Black 5v PS/2 RS232 Reader | RDR-80081AK2 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus V2 w/ iCLASS ID Black 5v Pin9 RS232 Reader | RDR-80081AK5 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus V2 w/ iCLASS ID Black 9v ext p.s. RS232 Reader | RDR-80081AK7 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus V2 w/ iCLASS ID Black 5v USB pwr tap RS232 Reader | RDR-80081AK9 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus Keystroke V2 w/ iCLASS ID & SEOS Black 6in. USB Reader | RDR-80081AKU-C06 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus Keystroke V2 w/ iCLASS ID & SEOS Black 16in. USB Reader | RDR-80081AKU-C16 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus Keystroke V2 w/ iCLASS ID & SEOS Black USB Reader | RDR-80081AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus SDK V2 w/ iCLASS ID & SEOS Black Virtual COM Reader | RDR-80082AK0 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | USB Virtual Com | |
| Wave ID® Plus SDK V2 w/ iCLASS ID & SEOS Black USB Reader | RDR-80082AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Raw Data | USB-A | |
| Wave ID® Plus Keystroke SP w/ iCLASS ID & Seos Black USB Reader | RDR-800H1AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Slim Profile | USB-A |
| Wave ID® Plus V2 Keystroke w/ iCLASS ID non-housed USB Reader | RDR-800N1AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus V2 w/ iCLASS ID Surface Mount Black 5v Pin 9 RS232 Reader | RDR-800W1AK5 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | Surface Mount | Serial |
| Wave ID® Plus V2 w/ iCLASS ID Surface Mount Black 5v USB pwr tap RS232 Reader | RDR-800W1AK9 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Serial | Surface Mount | Serial |
| Wave ID® Plus Keystroke V2 w/ iCLASS ID & SEOS Surface Mount Black USB Reader – 6FT cable | RDR-800W1AKU-C72 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Surface Mount | USB-A |
| Wave ID® Plus Keystroke V2 w/ iCLASS ID & SEOS Surface Mount Black USB Reader | RDR-800W1AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Surface Mount | USB-A |
| Wave ID® Plus SDK V2 w/iCLASS ID Surface Mount Black USB Reader | RDR-800W2AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS, HID™ iCLASS Seos™, HID™ iCLASS SE™, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, TechnoGym (Key Fob) CSN, Texas Instruments Tag-It CSN, Urmet, XceedID® MIFARE® CSN | Raw Data | Surface Mount | USB-A |
| Wave ID® Plus V2 Black Virtual COM Reader | RDR-80581AK0 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | USB Virtual Com | |
| Wave ID® Plus V2 Black 5v P/S 2. RS232 Reader | RDR-80581AK2 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus V2 Black 5v Pin 9. RS232 Reader | RDR-80581AK5 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus V2 Black 9v p.s. RS232 Reader | RDR-80581AK7 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | Serial | |
| Wave ID® Plus Keystroke V2 Black 6in. USB Reader | RDR-80581AKU-C06 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus Keystroke V2 Black 16in. USB Reader | RDR-80581AKU-C16 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus Keystroke V2 Black USB Reader | RDR-80581AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus SDK V2 Black USB Virtual COM Reader | RDR-80582AK0 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | USB Virtual Com | |
| Wave ID® Plus SDK V2 Black USB Reader | RDR-80582AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Raw Data | USB-A | |
| Wave ID® Plus Keystroke SP Black USB Reader | RDR-805H1AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Slim Profile | USB-A |
| Wave ID® Plus Keystroke SP Black USB Reader | RDR-805H1AKU-X | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Slim Profile | USB-A |
| Wave ID® Plus V2 Keystroke non-housed no cable 5v RS232 Reader | RDR-805N1-2 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Serial | |
| Wave ID® Plus V2 Keystroke non-housed USB Reader | RDR-805N1AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | USB-A | |
| Wave ID® Plus SDK V2 Black non-housed 6ft. USB Virtual COM Reader | RDR-805N2AK0 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | USB Virtual Com | |
| Wave ID® Plus SDK non-housed USB Reader | RDR-805N2AKU-C06 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, Corbin Russwin® UID, DIGITAG, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck UID, Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 15693 CSN, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NFC Type 2 CSN, NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Texas Instruments Tag-It CSN, XceedID® MIFARE® CSN | Raw Data | USB-A | |
| Wave ID® Plus V2 Surface Mount Black USB Virtual COM Reader | RDR-805W1AK0 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | Surface Mount | USB Virtual Com |
| Wave ID® Plus V2 Surface Mount Black 5v Pin 9 RS232 Reader | RDR-805W1AK5 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | Surface Mount | Serial |
| Wave ID® Plus V2 Surface Mount Black 9v ext p.s. RS232 Reader | RDR-805W1AK7 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Serial | Surface Mount | Serial |
| Wave ID® Plus Keystroke V2 Surface Mount Black 6 ft. USB Reader | RDR-805W1AKU-C72 | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Surface Mount | USB-A |
| Wave ID® Plus Keystroke V2 Surface Mount Black USB Reader | RDR-805W1AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Keystroke | Surface Mount | USB-A |
| Wave ID® Plus SDK V2 Surface Mount Black USB Reader | RDR-805W2AKU | aptiQ™ MIFARE® CSN, AWID, Bosch ReadyKey Pro UID, Cardax UID, CASI-RUSCO, CDVI, CEPAS CAN, Corbin Russwin® UID, Cotag, DIGITAG, Dimpna UID, EM 410x (4100/4102/4105/4200), Farpointe Data Pyramid, Farpointe Data Pyramid UID, GProx-II ID, GProx-II UID, HID™ iCLASS™ CSN, HID™ Prox, HiTag 1 CSN, HiTag 2 CSN, HiTag S CSN, Honeywell Nexwatch, I-tag CSN, ID Teck (128 Bits), Indala, Infineon my-d™ CSN, ISO 14443A CSN, ISO 14443B CSN, ISO 15693 CSN, ISONAS™, Kantech ioProx, Keri KC-10x UID, Keri KC-26x, Keri NXT UID, LEGIC Advant CSN (ISO 15693 / 14443A), MIFARE® Classic CSN, MIFARE® DESFire® EV1 CSN, MIFARE® Plus CSN, MIFARE® Ultralight CSN, NEDAP Prox, NFC Type 1 CSN (Topaz), NFC Type 2 CSN, NFC Type 3 CSN (Felica), NFC Type 4 CSN, NXP ICODE® SLI CSN, Oyster CSN, Paradox, Postech, RF Logics UID, Rosslare, SecuraKey-02 Radio Key®, SecuraKey e*tag® CSN, Sony FeliCa CSN, TechnoGym (Key Fob) CSN, Urmet, XceedID® MIFARE® CSN | Raw Data | Surface Mount | USB-A |
Điều kiện hoạt động
Tần suất hoạt động
Kép 125 kHz và 13,56 MHz
Phạm vi đọc tối đa điển hình
1,0 ”- 3,0” (2,5 – 7,6cm) tùy thuộc vào loại thẻ lân cận và điều kiện môi trường
Sự tiêu thụ năng lượng
Đơn vị USB: Điển hình 70 mA, tối đa 100 mA
Đơn vị nối tiếp: Điển hình 75 mA, tối đa 110 mA
Các loại thẻ được hỗ trợ
Để có danh sách đầy đủ các loại thẻ được hỗ trợ, hãy nhấp vào đây
Tính chất vật lý
Kích thước
3,6 in × 2,1 in × 0,7 in
(9 cm × 5,2 cm × 1,7 cm)
Cân nặng
4 oz
(113,4 g)
Màu Đen – Ngọc trai
Giá đỡ bề mặt – Đen, Trắng
Túi tích hợp phần cứng – Jack Black
Tùy chọn gắn kết
Vỏ Surface Mount có thể dễ dàng gắn trên bảng điều khiển, ki-ốt và các ứng dụng trong nhà khác. Nó được thiết kế để gắn chỉ với 1 “vít # 8 (không bao gồm), với lực tối đa là 6,25 in / lbs. Đầu đọc máy tính để bàn có cáp khớp nối để dễ dàng đặt trên máy tính để bàn, quầy và hơn thế nữa. Đầu đọc tuân thủ IP67 phải được cài đặt theo hướng dẫn cài đặt (kèm theo tất cả các đơn vị).
Chiều dài cáp
Máy tính để bàn – 6 inch, 16 inch & 6 ft
Gắn kết bề mặt – 13 in
Túi tích hợp phần cứng – Giá treo bên trong là 2 ¾ “, Giá treo bên ngoài là 6 ”. (Có sẵn độ dài tùy chỉnh. Hãy gọi cho bộ phận Bán hàng của chúng tôi theo số (866) 439-4884.)
Các chỉ số
Đèn LED ba trạng thái, tiếng bíp âm kép
Nguồn cấp
USB tự cấp nguồn
PoE
Serial RS-232: tồn tại một số tùy chọn nguồn
Giao diện
USB, RS-232 nối tiếp, Ethernet
Bộ phát triển phần mềm (SDK)
Không
Sử dụng môi trường
Nhiệt độ hoạt động
-30 ℃ đến 65 ℃
(-22 ℉ đến 150 ℉)
Phạm vi độ ẩm hoạt động
Độ ẩm tương đối 5% đến 95%, không ngưng tụ
Phạm vi nhiệt độ lưu trữ
-40 ℃ đến 85 ℃
(-40 ℉ đến 185 ℉)
Thông tin chung
Chứng chỉ
FCC, Hoa Kỳ; CE Mark, Châu Âu; RCM, Úc; IC, Bộ Công nghiệp Canada. Môi trường: RoHS, REACH. Vui lòng gọi cho rf IDEAS hoặc thông tin về các chứng chỉ khác.
Sự bảo đảm
Một năm cho các khiếm khuyết về vật liệu / tay nghề. Xem chính sách đầy đủ để biết chi tiết
